Product Details
Specifications:
| Turntable section | |
| Type | Belt Drive |
| Motor | DC Motor |
| SPeed | 33-1/3 rpm, 45 rpm |
| Servo System | PRS3 (Platter Rotation Speed Servo System) |
| Rotation Detection Precision | less than +/–0.05% (at 33-1/3 rpm) |
| Wow and Flutters | 0.1% |
| Signal-to-Noise Ratio | more than 67dB (A-weighted, 20kHz LPF) |
| Platter Material | Acrylic |
| Platter Size | Full-size (300mm diameter, 16mm thickness) |
| Platter Weight | approx. 1.4kg / 3.1 lbs. |
| Tone-arm section | |
| Type | Static Balanced S-shape Tone-arm (Height Adjustable) |
| Effective Arm Length | 223mm |
| Over-hang | 18mm |
| Tracking Error | less than 3 degrees |
| Stylus Pressure Range | 0 to 5g |
| Supported Cartridge Weight | 15 to 23g（incl. Headshell） |
| Height Adjust Range | approx. 6mm |
| Anti-skating Adjustent | Supported |
| Cartridge section | |
| Type | MM-type (equivalent to audio-technica AT100E) |
| Output Voltage | 4.5mV (1kHz, 5cm/sec.) |
| Stylus Pressure | 1.4g +/–0.4g |
| Cartridge Weight | 6.5g +/-0.2g |
| Headshell Weight | 10g (incl. Screw, Nuts and Wires） |
| Phono EQ Amplifier section | |
| Amplifier Type | MM-type (On/Thru switchable) |
| Analog Output | |
| Connector | RCA Pin x 1pair (gold-plated) |
| Output Voltage | Phono/Line switchable |
| Phono Output mode | 4.5mV (+/–3dB) |
| Line Output mode | 230mV (–13dBV) |
| Digital Outputs | |
| USB Output | |
| Connector | USB B-type x 1 (DC 5V 500mA Bus-power supply required from PC) |
| Signal Format | PCM, 8k / 11.025k / 16k / 22.05k / 32k / 44.1k / 48kHz, 16bit |
| Compatible OS | Windows 7 Windows 8 Windows 8.1 Windows 10 OS X Lion (10.7) OS X Mountain Lion (10.8) OS X Mavericks (10.9) OS X Yosemite (10.10) OS X El Capitan (10.11) macOS Sierra (10.12) |
| Optical Output | |
| Connector | TOS-link x 1 |
| Signal Format | PCM (S/PDIF), 48k / 96k / 192kHz, 24bit |
| Output Level | -21.0 to -15.0dBm |
| Operation Power | AC 100 to 240V 50/60Hz |
| Power Consumption | 1.5W (0.5W at Standby) |
| Overall Dimensions | 430 x 131.5 x 355mm / 16.9" x 5.2" x 14.0 (W x H x D, incl. protrusions) |
| Weight | approx. 9.0kg / 19.9 lbs. |
| Accessories | AC Adapter (GPE053A-120050-Z), EP Adapter, Counter Weight, Head-shell, Cartridge (except. Canada model), Acrylic Platter, Dust Cover, Hinges x 2, Pulley Cover, Flat Belt, Washers x 4, Hex Wrench, RCA Audio Cable with GND terminals, Owner's Manual (incl. Warranty card) |
